Products

DOWE CH3-10Q /150 630A-1250A Epoxy Resin High Voltage Electrical Busbar Insulator Contact Box

OEM service: 1、Color: support red ,brown or other customsized 2、Insert: support brass,steel or other 3、Model: support OEM model
Model:
CH3-10Q/150 630-1250A
Voltage:
10KV
Height:
250mm
Material:
Epoxy resin
MOQ:
2 pieces
Certificate:
CE,ROHS,REACH,SGS

DOWE CH3-10Q /150 630A-1250A Epoxy Resin High Voltage Electrical Busbar Insulator Contact Box

DOWE CH3-10Q /150 630A-1250A Epoxy Resin High Voltage Electrical Busbar Insulator Contact Box

Insulation Contact Box Description

The contact box product uses epoxy resin material with excellent insulation performance, and is injection molded using the static mixed APG process commonly used in the market. It uses high-quality pressure-resistant, partial discharge and other testing equipment to strictly control the product quality in accordance with national standards.

Product name Contact box
Brand name DUWAI
Place of origin Zhejiang Province, China
Material Epoxy resin
Model CH3-10Q/150 630-1250A
Voltage 10KV
Current 630A-1250A
Application High voltage
Operating temperature -30℃~45℃
Certificate CE,ROHS,REACH

If you have any questions, please don't hesitate to contact us.
