DOWE 10KV High Voltage Epoxy Resin Contact Box CH3-10Q/150 630-1250A Electrical Contact Box For Switch Gear Industry Equipment
OEM service:
1、Color: support red ,brown or other customsized
2、Insert: support brass,steel or other
3、Model: support OEM mode
- Model:
- CH3-10Q/150 630-1250A
- Voltage:
- 10KV
- Height:
- 250mm
- Material:
- Epoxy resin
- MOQ:
- 2 pieces
- Certificate:
- CE,ROHS,REACH,SGS
Insulation Contact Box Description
The contact box product uses epoxy resin material with excellent insulation performance, and is injection molded using the static mixed APG process commonly used in the market. It uses high-quality pressure-resistant, partial discharge and other testing equipment to strictly control the product quality in accordance with national standards.
| Product name | Contact box |
| Brand name | DUWAI |
| Place of origin | Zhejiang Province, China |
| Material | Epoxy resin |
| Model | CH3-10Q/150 630-1250A |
| Voltage | 10KV |
| Current | 630-1250A |
| Application | High voltage |
| Customized | OEM,ODM |
| Certificate | CE,ROHS,REACH |
If you have any questions, please don't hesitate to contact us.
