630A Integrated Casing Bushing Cable Connector Branch Box Cable Accessories
630A butt bushing, mainly used for European-style cable branch box, connected to European-style front connector, can be connected to the live indicator, showing the bus live state. It uses high-qualit
- Model:
- SQTG-12 24KV 630A
- Voltage:
- 12/24KV
- Current
- 630A
- Height:
- 260
- Diameter:
- 124
- Screw:
- M12
- Material:
- Epoxy resin
- MOQ:
- 2 pcs
- Certificate:
- CE,RoHS,SGS,REACH
630A butt bushing, mainly used for European-style cable branch box, connected to European-style front connector, can be connected to the live indicator, showing the bus live state. It uses high-quality epoxy resin insulation material.
Application
630A bushing is used to connect with 630A cable connector on branch box with SF6 load switch. It is made of high-quality epoxy resin. The design of the umbrella skirt structure increases the creepage distance, improves the electrical performance of the equipment, and greatly improves the electrical safety.
Our service
|
Delivery |
By express/By sea/By air/By land transportation |
|
Supply |
5000pcs/week |
|
Sample |
The seller provides 2 samples for free, and the buyer pays the freight |
|
Packing |
By carton |
