One-Two Umbrella Sleeve 630A Skirt as Wall Bushing

630A butt bushing, mainly used for European-style cable branch box, connected to European-style front connector, can be connected to the live indicator, showing the bus live state. It uses high-qualit
Model:
JTG-12KV 630A
Voltage:
12kv
Current
630A
Material:
Epoxy resin
MOQ:
2 pcs
Certificate:
CE,RoHS,SGS,REACH

One-Two Umbrella Sleeve 630A Skirt as Wall Bushing

630A butt bushing, mainly used for European-style cable branch box, connected to European-style front connector, can be connected to the live indicator, showing the bus live state. It uses high-quality epoxy resin insulation material.

Application

630A bushing is used to connect with 630A cable connector on branch box with SF6 load switch. It is made of high-quality epoxy resin. The design of the umbrella skirt structure increases the creepage distance, improves the electrical performance of the equipment, and greatly improves the electrical safety.

Our service

Delivery

By express/By sea/By air/By land transportation

Supply

5000pcs/week

Sample

The seller provides 2 samples for free, and the buyer pays the freight

Packing

By carton
