DOWE TGZS-35KV 630A Epoxy Resin European Type Cable Casing Seat Electric Accessories Series For Switch Cabinet
OEM service:
1、Color: support red ,brown or other customsized
2、Insert: support brass,steel or other
3、Model: support OEM model
- Model:
- TGZS-35KV 630A
- Voltage:
- 35kv
- Height:
- 353
- Diameter:
- 127
- Screw:
- M16
- Material:
- Epoxy resin
- MOQ:
- 2 PCS
- Certificate:
- CE,ROHS,SGS,REACH
European Casing Seat Socket Description
35kv 630A bushing socket, which provides an interface for 630A cable connectors, mainly used in wind energy substations. It is
installed on one side of the box transformer and connected to the high-voltage winding, and it is installed on the outdoor ring
network cabinet as the 630A outlet side. Connect with shielded bolted cable glands.
It's material is an epoxy resin with good mechanical and electrical properties.
| Product name | European type cable casing seat |
| Model | TGZS-35KV 630A |
| Rated voltage | 35KV |
| Rated current | 630A |
| Height | 353 |
| Diameter | 127 |
| Material | epoxy resin |
| Application | voltage transformer |
| Customized | OEM,ODM |
| Certificate | CE,ROHS,REACH |
If you have any questions, please don't hesitate to contact us.
