DOWE 24KV Indoor Epoxy Resin High Quality Epoxy Resin Busbar Support Post Insulator For Distribution Cabinet

OEM service: 1、Color: support red ,brown or other customsized 2、Insert: support brass,steel or other 3、Model: support OEM mode
Model:
CG5-24Q/110X210,225
Voltage:
24KV
Height:
210,225mm
Material:
Epoxy resin
MOQ:
2 pieces
Certificate:
CE,ROHS,REACH

DOWE 24KV Indoor Epoxy Resin High Quality Epoxy Resin Busbar Support Post Insulator For Distribution Cabinet

DOWE 24KV Indoor Epoxy Resin High Quality Epoxy Resin Busbar Support Post Insulator For Distribution Cabinet

High voltage insulator sensor description

The high-voltage sensor extracts a certain voltage from the high-voltage charged circuit by pumping the capacitor core rod as the power supply for display and blocking, which is used to reflect the charged state of the device setting, and can forcibly lock and switch the net door. The work of voltage indication and forced locking are controlled by the same high voltage signal, but the circuit system is independent of each other. As long as the high voltage circuit is charged, even if the display circuit and the locking circuit fail at the same time, the electromagnetic lock is still in the locked state. Therefore, the product has high reliability and high safety.

High voltage sensor insulator is a kind of cylindrical insulator product cast with epoxy resin, which can be used as post insulator of disconnecting switch, grounding switch, etc. It has the characteristics of high strength, strong arc resistance, and small partial discharge.

Product name High voltage sensor
Model CG5-24Q/110X210,225
Voltage 24KV
Height 170mm
Material Epoxy resin
Application High voltage cabinet
Certificate Certificate

If you have any questions, please don't hesitate to contact us.
